Wall washer

Light emission on one side

Lateral throw

  LED   A B C
22 383 15.8W 2187 lm
9 ½
4
7
33 378 26.6W 3676 lm
12 ½
5
8

Asymmetric

  LED EXPRESS   A B C
22 386 17.9W 2352 lm
9 ½
4
7
33 386 43.4W 4549 lm
12 ½
5
8

Symmetric

  LED EXPRESS   A B C
22 392 17.9W 2910 lm
9 ½
4
7
33 388 43.3W 4853 lm
12 ½
5
8

Wall washer
Light emission on one side

A series of LED wall mounted luminaires with symmetrical, asymmetrical, or wide spread light distribution. Symmetrical light distribution is used to illuminate facade and wall surfaces, with the installation surface also acting as the reflection surface. Asymmetrical light distribution to illuminate ceiling or ground surfaces in front of the mounting surface. Wide spread light distribution to illuminate ground surfaces along walls.
Die-cast aluminum · Safety glass · Reflector made of pure anodized aluminum
LED color temperatures: 2700K, 3000K, 3500K, 4000K
All BEGA standard finishes are matte, textured powder coat with minimum 3 mil thickness. BEGA Unidure® finish, a fluoropolymer technology, provides superior fade protection in Black, Bronze, and Silver. BEGA standard White, as well as optionally available RAL and custom colors, are a polyester powder.
NRTL listed to North American standards - Suitable for wet locations - Protection class IP 65
