In-grade luminaire

Cast-in-place
Big Product
Big Product
Big Product
Big Product
Big Product
Big Product
Big Product
Big Product
View all photos View catalog page

Location luminaire

  LED   A B C
77 055 link 2.1W link link link 93 lmlink link
5 ¾ link
10 ⅝ link
7 ½ link
77 056 link 3.0W link link link 79 lmlink link
8 link
10 ⅝ link
7 ½ link
77 057 link 3.9W link link link 125 lmlink link
9 ⅝ link
12 ¼ link
8 ¼ link
77 058 link 8.4W link link link 205 lmlink link
13 link
16 link
10 link

Symmetric

  LED   β A B C
77 006 link 8.2W link link link 470 lmlink 17° link
8 link
10 ⅞ link
7 ½ link
77 007 link 13.9W link link link 970 lmlink 16° link
9 ⅝ link
12 ¼ link
8 ¼ link
77 040 link 36.2W link link link 1894 lmlink 19° link
13 link
16 link
10 link

Asymmetric

  LED   β A B C
77 105 link 3.0W link link link 399 lmlink 24x24° link
5 ¾ link
10 ⅝ link
6 ⅝ link
77 106 link 10.5W link link link 800 lmlink 28x29° link
8 link
10 ⅝ link
7 ½ link
77 107 link 13.9W link link link 1915 lmlink 30x32° link
9 ⅝ link
12 ¼ link
8 ¼ link
77 116 link 36.2W link link link 3349 lmlink 30x35° link
13 link
16 link
10 link

Adjustable

  LED EXPRESS   β A B C
77 145 link 3.0W link link link 284 lmlink 28° link
5 ¾ link
10 ⅝ link
6 ¾ link
77 146 link 5.7W link link link 568 lmlink 16° link
8 link
10 ⅝ link
7 ½ link
84 115 link 18.5W link link link 1130 lmlink 9° link
11 link
13 ¾ link
8 ⅜ link
77 147 link 19.3W link link link 945 lmlink 15° link
11 link
13 ¾ link
8 ⅜ link
77 148 link 17.2W link link link 1391 lmlink 15° link
13 link
15 ½ link
10 link

Wall washer

  LED   β A B C
84 153 link 7.8W link link link 838 lmlink 55x40° link
8 ⅛ link
10 ⅝ link
7 ½ link
84 154 link 13.7W link link link 1488 lmlink 54x41° link
9 ⅝ link
12 ¼ link
8 ¼ link
84 155 link 27.4W link link link 2941 lmlink 55x41° link
12 ⅞ link
15 ½ link
10 link

In-grade luminaire
Cast-in-place

In-grade location and floodlight luminaires. Available in location, symmetric, asymmetric, adjustable and wall washer distributions. These luminaires are designed to bear pressure loads up to 4400 lbs. from vehicles with pneumatic tires. The luminaires must not be used for traffic lanes where they are subject to horizontal pressure from vehicles braking, accelerating and changing direction.

Stainless steel housing and faceplate · Clear or white safety glass · Floodlight reflectors made of pure anodized aluminum

LED color temperatures: 2700K, 3000K, 3500K, 4000K

Brushed stainless steel. Custom colors are not available.

NRTL listed to North American standards - Suitable for wet locations - Protection class IP 68 10m
